2400 Series SourceMeter
®
User’s Manual Getting Started 1-27
These various configuration menus are covered in detail in the pertinent sections of this
manual.
Table 1-6
Measurement configuration menus
Configuration menu item Description
CONFIG MEAS V
SENSE MODE
2-WIRE
4-WIRE
CMPL-RANGE-SYNC
CONFIG MEAS I
CMPL-RANGE-SYNC
CONFIG MEAS Ω
CONFIG OHMS
SOURCE
MANUAL
AUTO
SENSE MODE
2-WIRE
4-WIRE
GUARD
OHMS
CABLE
OFFSET COMPENSATION
DISABLE
ENABLE
SRC RDBK
DISABLE
ENABLE
CONFIG FCTN
CONFIGURE FUNCTION
POWER
OFF COMP OHMS
VOLT-COEFF
VAR ALPHA
%DEV
Configure V measure.
2-wire mode (local sensing).
4-wire mode (remote sensing).
Enable (ON) or disable (OFF) measure and compli-
ance range synchronization.
Configure I measure.
Enable (ON) or disable (OFF) measure and compli-
ance range synchronization.
Configure ohms measure.
Select manual or auto source for ohms.
Select 2-wire or 4-wire mode.
Select ohms or cable guard.
Enable/disable offset compensation.
Enable/disable source readback.
Configure functions.
Enable power function.
Enable offset-compensated ohms, program
parameters.
Enable voltage coefficient, program parameters.
Enable varistor alpha, program parameters.
Enable percent deviation, program parameters.
