2400 Series SourceMeter
®
User’s Manual Digital I/O Port, Safety Interlock, and Output Configuration 13-11
Remote output configuration
Output configuration commands
Table 13-2 summarizes output configuration commands. These commands include those
to enable and disable the interlock as well as commands to control output off states. See
Section 18, “OUTPut subsystem” and “SOURce subsystem” for more information.
Table 13-2
Output configuration commands
Command Description
:OUTPut:INTerlock:STATe <state>
:OUTPut:INTerlock:TRIPped?
:OUTPut:SMODe <name>
:SOURce:CLEar
:SOURce:CLEar:AUTO <state>
:SOURce:CLEar:AUTO:MODE <name>
Enable/disable interlock (state = ON or OFF).
Query interlock tripped state (1 = tripped).
Select output-off mode (state = HIMPedance, NORMal, ZERO,
or GUARd).
1
Turn output source off when in idle state.
Enable/disable auto output-off. State = ON (output off after
measurement) or ON (output stays on).
2
Auto clear mode. Name = ALWays (every reading; default) or
TCOunt (ON when trigger layer entered; OFF when leaving
trigger layer).
1. For the Model 2430 Pulse Mode, the output-off mode is always NORMal. Selecting one of the other output-off states causes error
+831.
2. For the Model 2430 Pulse Mode, auto output-off is always enabled. You can set auto output to be off, but it will not disable until
the DC Mode of operation is selected.
