6. Setup
MKC-710 73
Interface 6-1.
Select “1.Interface” with [↑][↓] and press [ENTER].
6-1-1.RS-232C setting
Select “1.RS-232C” with [↑][↓] and press [ENTER].
[Interface]
Select a COM port on which you wish to output RS-232C. Only one RS-232C can be
connected. Select where a printer or a balance is not connected.
x COM1 : RS output is set to COM1.
x COM2 : RS output is set to COM2.
[Baud Rate]
Select baud rate:
x 300 bps /600 bps / 1200 bps / 2400 bps / 4800 bps / 9600 bps
[Parity]
Select parity:
x NONE/EVEN/ODD
[Stop Bits]
Select stop bits:
x 1bit / 2bits
[Data Bits]
Select data bits:
x 7bits / 8bits
When you want to transfer the output data to a personal computer, you need to
purchase our optional Data Acquisition Software (SOFT-CAP). But you have to
check the version of the Data Acquisition Software because some software
cannot be compatible with the titrator. For more information, please contact
your sales representative nearest to or local dealer.
