KEM MKC-710 - Date Acquisition Software (SOFT-CAP); Printer Setting

6. Setup
74
6-1-2.Date acquisition software (SOFT-CAP)
The optional software SOFT-CAP is Windows£-based application and can download the
measurement data to Microsoft£ Excel£ workbook or store in CSV format through
RS232C port.
By this software, starting titration or reset can be commanded by the computer.
＜Receiving date＞
The SOFT-CAP software can export the measurement results as follows:
1) It transfers the data to Microsoft£ Excel£ workbook.
2) It stores the data in CSV format so that spreadsheet can be used.
＜Sending date＞
The personal computer can send commands including titration start and reset.
Note
For details, see the operation manual for Data Acquisition Software (SOFT-CAP).
6-1-3.Printer setting
<IDP-100>
Connect the IDP-100 to COM1.
<DP-600>
Connect the DP-600 to the USB port.
Select “2．Printer” with [↑][↓] and press [ENTER].
