6. Setup
MKC-710 75
[Printer]
Select a type of printer you are going to use: Select “NONE” if no printer is
connected.
x NONE ：No printer.
x IDP- ：KEM’s impact dot printer model IDP-100.
x DP-USB ：Select this when connecting our thermal printer (DP-600) to
the USB port.
x OTHER ：Other printer than the below.
Connect to COM1 when selecting ‘IDP-‘ or ‘OTHER’. Connecting to COM2 leads
to failure in printing.
For printer type and configurations, refer to the Table 6-1-3-1. The
communication protocol between your printer and titration unit must match.
Otherwise, printing may fail and halt halfway. For digital configurations for your
printer, refer to the operation manual for the printer.
[Baud Rate]
If you use other printer as defined on ［Printer］, you have to select baud rate for your
printer:
x 300 bps /600 bps / 1200 bps / 2400 bps / 4800 bps / 9600 bps
[Parity]
If you use “Other” printer as defined on ［Printer］, you have to select parity for your
printer:
x NONE/EVEN/ODD
[Stop Bits]
If you use “Other” printer as defined on ［Printer］, you have to select stop bits for
your printer:
x 1bit / 2bits
[Data Bits]
If you use “Other” printer as defined on “Printer”, you have to select data bit for your
printer:
x 7bits / 8bits
Table6-1-3-1
Citizen
CBM-910
CBM-910
TypeⅡ
Connecting cable
12-02013
64-00625
Digital configurations for printer:
Baud rate ：4800
Parity ：none
Stop bits ：1
Data bits ：8
