12. Measure
controls
The measure controls consist of:
• Cursors knob — Push this knob select cursors from a popup menu. Then,
after the popup menu closes (either by timeout or by pushing the knob
again), rotate the knob to adjust the selected cursor position.
•[Cursors] key — Press this key to open a menu that lets you select the
cursors mode and source.
•[Meas] key — Press this key to access a set of predefined
measurements. See Chapter 14, “Measurements,” starting on page
181.
13. Waveform keys The [Acquire] key lets you select Normal, Peak Detect, Averaging, or High
Resolution acquisition modes (see “Selecting the Acquisition
Mode" on page 161) and use segmented memory (see “Acquiring to
Segmented Memory" on page 167).
The [Display] key lets you access the menu where you can enable
persistence (see “To set or clear persistence" on page 115), clear the
display, and adjust the display grid (graticule) intensity (see “To adjust
the grid intensity" on page 117).
14. File keys Press the [Save/Recall] key to save or recall a waveform or setup. See
Chapter 18, “Save/Recall (Setups, Screens, Data),” starting on page 229.
The [Print] key opens the Print Configuration Menu so you can print the
displayed waveforms. See Chapter 19, “Print (Screens),” starting on page
241.
15. [Help] key Opens the Help Menu where you can display overview help topics and
select the Language. See also “Access the Built-In Quick Help" on
page 47.
