Data Analysis Features
All about Markers
— When a marker is moved to a ‘blank’ trace (not visible) the marker
moves to the same X-axis position at either the Y-axis position of the
last data, or to the ZERO position.
Marker Format
The Marker Format setting allows you to choose the format of the marker
readout that appears in the upper-right corner of the screen and in the marker
table. The marker format can be independent of the trace format, and can be
set independently for each trace. All markers on a trace have the same marker
format.
How to choose marker format
—Press Marker.
—Then More
.
—Then Marker Format
.
— Then choose from the following:
There are more trace formats available than marker formats. To display marker
readouts in more formats than are shown here, change the trace format, then
select Default. Learn how to change format in “Format” on page 5-7.
Searching with Markers
Marker Searches are used to move markers to locations on the trace which
exhibits the characteristics of the search criteria. Learn “What Is a ‘Peak’” on
page 16-10.
Selection Example Y-axis value
Default Same as displayed format
R + jX Complex impedance format
(3rd number is distance for Time Domain)
22.8Ω -j61.4Ω
287.9fF
Z Magnitude Impedance Mag. 66.08Ω
Phase 73.8°
Real 0.2003
More
Imaginary -0.6727
Mag & Phase 0.705, -73.7°
