Maintenance
547
Fuses
MODULE8 10A
AMP (Amplifier), Driver IMS (Integrated memory system) Module, Front
Wireless Charger, Front Air Ventilation Seat Control Module, Front/Rear
Seat Warmer Control Module, ATM (Automatic Transmission) Shift Lever
Indicator, Data Link Connector, Audio, Audio/Video & Navigation Head Unit,
Air Conditioner Switch, Surround View Monitor Unit, Air Conditioner Control
Module, DC-DC Converter (Audio/AMP (Amplifier)), Electro Chromic Mirror
MODULE2 10A
Cooling Fan Motor, Parking Collision Avoidance Assist Unit, Front/Rear Seat
Warmer Control Module, Front Air Ventilation Seat Control Module, Engine
Room Junction Block (W/S Heated Glass Left Handle side/Right Handle side
Relay)
MDPS 7.5A MDPS (Motor Driven Power Steering) Unit (Column Type)
A/C1 7.5A
Air Conditioner Control Module, Air Conditioner Switch, Engine Room Junc
-
tion Block (Blower Relay)
MODULE4 10A
Rear USB Charger, PCB Block (Power Outlet Relay), Console USB Charger
(Outside Rear Left Handle side/Right Handle side), Console USB Charger
(Inside), AMP (Amplifier), IBU (Integrated Body Control Unit), DC-DC Con
-
verter (Audio/AMP (Amplifier)), Audio, Audio/Video & Navigation Head Unit,
Surround View Monitor Unit, Parking Collision Avoidance Assist Unit
MODULE9 7.5A IBU (Integrated Body Control Unit)
CLUSTER 10A Instrument Cluster, Head-up Display
WASHER 15A Multifunction Switch
START 7.5A
B/Alarm Relay, IBU (Integrated Body Control Unit), ECM (Engine Control
Module), Transmission Range Switch, Engine Room Junction Block (Start
Relay)
POWER OUTLET 20A Not Used
IBU2 7.5A IBU (Integrated Body Control Unit)
A/BAG IND 7.5A Instrument Cluster, Overhead Console Lamp
SPARE2 10A Not Used
A/C2 10A Air Conditioner Control Module
Fuse Name Fuse rating Circuit Protected
