Maintenance
667
Light bulbs
Replacing rear tail & stop lamp,
stop lamp, turn signal lamp, back
up lamp bulb (Bulb type)
Type A
Type B
1. Tail and stop lamp
2. Tail lamp (center)
3. Turn signal lamp
4. Back up lamp
To replace the bulb:
1. Engage the parking brake, shift to
P and turn the ignition OFF.
2. Turn of the rear combination
lamp.
3. Open the trunk.
4. Remove the rear combination
lamp assembly or rear trunk trim
from the body of vehicle using the
flat-blade screwdriver.
5. Remove the socket from the
assembly by pressing it in and
rotating it counterclockwise.
6. Pull the bulb out of the socket.
7. Insert a new bulb into socket.
8. Push the socket into the assem
-
bly and turn the socket clockwise.
9. Reinstall the assembly to the
body of the vehicle.
