Maintenance Fuses
PCB Block: Smartstream G2.5 T-GDi
Fuse Name Fuse rating Circuit Protected
WIPER1 30A PCB Block (Wiper Relay)
WIPER2 10A
IBU (Integrated Body Control Unit), ECM (Engine Control
Module)
TCU1 20A Not Used
ECU2 15A ECM (Engine Control Module)
ECU1 20A ECM (Engine Control Module)
ECU4 15A ECM (Engine Control Module)
TCU2 15A TCM (Transmission Control Module)
A/C1 10A Engine Room Junction Block (Air Conditioner Relay)
INJECTOR 15A Injector #1 ~ #4
SENSOR1 15A Oxygen Sensor (Up/Down)
POWER OUTLET2 20A Front Power Outlet Left Handle side
POWER OUTLET3 20A Front USB Charger
HORN 20A PCB Block (Horn Relay)
SENSOR2 10A
Oil Control Valve (Exhaust), Variable Oil Pump Solenoid
Valve, Purge Control Solenoid Valve, RCV (Recirculation
Valve Control) Control Solenoid Valve, Canister Close
Valve, Engine Room Junction Block (Air Conditioner
Relay)
FUEL PUMP2 10A Engine Room Junction Block (Fuel Pump Relay)
ECU3 10A ECM (Engine Control Module)
ABS3 10A ESC (Electronic Stability Control) Module
IGN COIL 20A Ignition Coil #1 ~ #4
CRUISE 10A Smart Cruise Control Unit
To Next Page
