P/N 06-236530-001 3-23 August 2013
3-2.5.2.3.6 How to List a Range of Automatic Detector Sensitivity Settings
Purpose: To view the pre-alarm and alarm thresholds for a range of
automatic detectors and to view the fire signatures being currently
measured by the detectors. This procedure fulfills the intent of NFPA
72 (2002) Paragraph 10.4.3.2.4, Part (4) as a test to ensure that each
smoke detector is within its listed and marked sensitivity range.
3-2.5.2.3.7 How to List Active Events
Purpose: To view the list of active events by event type. Use this option
to view lower-level events such as trouble events whose display is
suppressed by the concurrent occurrence of higher-level events.
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password; Press “Enter” Key Gain access to menus
3 Press 2 Key Enter List-Menu branch
4 Press 3 Key Access "Detector Level" option
5 Enter Start Address and End Address. Use XXX
format for address.
Press "Enter" Key to confirm address selection.
View detectors' pre-alarm and alarm thresholds
and levels of fire signatures being measured.
Format for smoke detectors is:
Addr TP Pre-Alm Alm Level
Format for heat detectors is:
Addr. TP Pre-Alm Level
where:
“Addr” is the device address
“TP” is the device type
“Pre-Alm” is pre-alarm setting in either %/Ft. or
°F
“Alm” is alarm setting in either %/Ft. or °F
“Level” is current reading in either %/Ft. or °F
6 Press “Scroll” Key (as required) Move through list of selected detectors
7 Press "Backspace" Key (as required) Exit Menu System
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password; Press “Enter” Key Gain access to menus
3 Press 2 Key Enter List-Menu branch
4 Press "Scroll" Key Access additional options
5 Press 4 Key Access "Active Events" option
6 Press 1 Key for Pre-Alarm Events or
Press 2 Key for Alarm Events or
Press 3 Key for Supervisory Events or
Press 4 Key for Trouble Events.
Select event type to view
7 Press "Scroll" Key (as required) Move through list of selected events
8 Press "Backspace" Key (as required) Exit Menu System
