P/N 06-236530-001 3-43 August 2013
3-2.5.2.4.13 How to Configure a Remote Release
Purpose: To change one or more of the following Remote Release
Module (RRM) operating characteristics for a single or range of
modules: solenoid and actuator.
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password; Press “Enter” Key Gain access to menus
3 Press 3 Key Enter Set-Menu branch
4 Press 3 Key Access "SLC Devices" option
5 Press 2 Key Select "Configuration"
6 Press "Scroll" Key Access additional options
7 Press 5 Key Select “Remote Release”
8 Use keypad to enter single module or range of
modules to change configuration settings.
Press "Enter" Key to confirm selection.
Specify modules to change
9 Press 1 Key for solenoid or
Press 2 Key for actuator
Specify Remote Release application.
10 Wait until "x RRM(s) Updated" message
disappears from the display.
Enable/Disable pre-alarm reporting
11 Press "Backspace" Key (as required) Exit Menu System
