P/N 06-236530-001 5-7 August 2013
SG3 Short Circuit Trouble On Short circuit in field wiring connected
to main circuit board TB7. Combo-1
Circuit is configured as a NAC.
• Troubleshoot Combo-1 wiring by
breaking-up circuit to isolate short
circuit to specific leg.
SG4 Open Circuit Trouble On Open circuit in field wiring connected
to main circuit board TB6. Combo-2
Circuit is configured as a NAC.
• Check for missing 10k end-of-line
resistor.
• Look for discontinuity in Combo-2
field wiring.
SG4 Short Circuit Trouble On Short circuit in field wiring connected
to main circuit board TB6. Combo-2
Circuit is configured as a NAC.
• Troubleshoot Combo-2 wiring by
breaking-up circuit to isolate short
circuit to specific leg.
Table 5-3. SLC Events
SLC Events
Error Message Probable Cause Corrective Action
Addr Switch Not Set On AlarmLine
Module
An incorrect configuration for the
AAM at address Addr
• Check the configuration settings for
the AAM. Re-configure and upload
the correct configuration.
• Refer to AlarmLine Installation,
Operation, and Maintenance
Manual, P/N 73.04
Addr 24 Vdc Failure Signal/ Sounder Failure of the DC to DC converter in
the ASM at address Addr
• Refer to ASM Installation
Instructions, P/N 06-235717-001.
• Check 24 Vdc power connections to
ASM.
• Ensure that the ASM's Jumper P1
and Switch S1 are set for 24 Vdc
operation
• Replace the ASM if steps above are
unsuccessful
Table 5-2. Control-Unit-Based-Output Events (Continued)
Control-Unit-Based-Output Events
Error Message Probable Cause Corrective Action
