Kidde ARIES

Battery Calculations
August 2013 A-2 P/N 06-236530-001
-MT-2475 * - ----0.157---
-MIZ-24 * - ----0.012---
-MIZ-TC24 * - ----0.017---
-NH-12/24 * - ----0.015---
- NS-241575 * - ----0.079---
-NS-24MC (Horn only) * - ----0.015---
-NS-24MC (w/15 cd) * - ----0.058---
-NS-24MC (w/30 cd) * - ----0.082---
-NS-24MC (w/75 cd) * - ----0.140---
-NS-24MC (w/110 cd) * - ----0.174---
-MB-G6-24 * - ----0.030---
-MB-G10-24 * - ----0.030---
- RSS-241575 * - ----0.065---
-RSS-24MC (15 cd) * - ----0.050---
-RSS-24MC (30 cd) * - ----0.081---
-RSS-24MC (75 cd) * - ----0.133---
-RSS-24MC (110 cd) * - ----0.161---
-SM Synch. Module * - ----0.025---
-DSM Synch. Module * - ----0.038---
- 897494 - ----1.500---
- 486500-01 - ----0.240---
- - ---- ---
-FM Solenoid (Group A) - ----0.458---
-FM Solenoid (Groups B,D) - ----0.700---
-FM Solenoid (Groups E,G) - ----0.420---
Total Standby Current (A) _______ Total Alarm Current (A) _______ _______ _______
Standby Hours _______ Alm Minutes _______ _______ _______
Standby AH _______ Alarm AH _______ _______ _______
Total AH _______ _______ _______
Battery Size (AH) _______ _______ _______
Battery Capacity for Calculations(AH) (10% De-rating) _______
Max. Alarm Current (A) 5.400
+ (Qty) X (Unit Standby Current)
# (Alm Qty) X (Unit Alm Current)
& (Pre-Rel. Qty) X (Unit Alm Current)
$ (Rel. Qty) X (Unit Alm Current)
* Typical currents. Refer to specific product information sheets.
Table A-1. Calculating Operating System Current Load (Continued)
