Handheld-Programmer Operating Instructions
P/N 06-236530-001 D-3 August 2013
5. After about 10 seconds, the entered address will be displayed on the top row of the display.
6. Repeat Steps 1 through 5 for each device to be addressed.
D-7 BATTERY REPLACEMENT
1. Ensure that the power switch is off (down position) and that the power cord is
disconnected.
2. Remove the four Phillips-head screws from the back panel of the Programmer.
3. Lift the rear panel from the unit carefully, preventing tension to the wiring connected
to the rear panel PC board. Place rear panel on the side of the unit. Do not disconnect
interconnecting wiring.
4. Remove the two Phillips-head screws securing the battery bracket. Lift out the bracket.
5. Remove battery pack and disconnect battery connector.
6. Insert new battery pack by reversing the steps above.
D-8 POWER SPECIFICATIONS ADDRESSABLE SIGNAL MODULE
AC Input Rating: 120Vac, 1.0A (Max.)
DC Output Rating: 12Vdc, 1.75A (Max.)
Battery Rating: 7.2Vdc, 700 mAH
Table D-2. Supported Devices
Supported Devices Part Number
Ionization Detectors 70-402001-100
70-401001-000
70-401002-000
70-401004-000
Photoelectric Detectors 71-402001-100
71-401001-000
71-401002-000
71-401004-000
Thermistor Heat Detector 70-404001-100
Addressable Contact Input Devices 70-407002-00X
70-407003-001
70-407004-001
70-4070x8-00x
Relay Devices 70-408001-000
70-408003-000
70-4080x4-001
Addressable Signal Module 70-200200-00X
