Kidde FX-64

Chapter 2: Front panel programming
P/N 3102352-EN • REV 005 • ISS 28DEC18 87
7. Add the detector as an input and the sounder base as an output. Choose:
Sensor to add the detector
— or —
Base to add the sounder base.
8. On the Status line, press Enter to select Included. This adds the device to the group.
9. Repeat steps 4 to 8 to add or remove other devices, zones, or NACs.
10. Repeat steps 3 to 9 to program additional correlation groups.
11. Press the Menu button to exit menu mode, or continue programming.
Device programming
Each device that operates on a notification appliance circuit (NAC) or device loop has
operating parameters that must be set. This includes assigning a device type and label,
programming event notification, etc.
Table 28: Programming devices — Device options
Option
Description
Zone
Identifies the zone to which the device will be added.
To add the device to a zone, enter the zone number.
— or —
If the device will not be added to a zone, select Off.
Note: Do not mix device and zone types. For example, do not place a nonlatching
supervisory device in an alarm zone. When the supervisory device activates and an alarm
event is initiated, the alarm event automatically clears when the device restores without
having to reset the panel.
Zone secondary
Identifies the zone to which the device’s secondary element (if it exists) will be added.
To add the device to a zone, enter the zone number.
— or —
If the device will not be added to a zone, select Off.
Note: Do not mix device and zone types. For example, do not place a nonlatching
supervisory device in an alarm zone. When the supervisory device activates and an alarm
event is initiated, the alarm event automatically clears when the device restores without
having to reset the panel. Be sure to name your zones appropriately in message line 1 for
CO activations.
Label
Contains the two lines of text displayed beneath the device number on the LCD.
1. Enter text for the device label (two lines of 20 characters).
2. When you have finished, choose Save.
Event notification
Sets notification options (printer, coder, dialer, and contact ID) for the active, alarm verify,
disable, maintenance, prealarm, test, trouble, and active3 for secondary events. See
“Factory default settings” on page 41 for device event notification default settings.
