Chapter 3: System operation
134 P/N 3102352-EN • REV 005 • ISS 28DEC18
Description
SLC card connector (J7): Provides a connection for an additional SLC card (only on the
FX-1000 panel)
Class A card connector (J2): Provides a connection for the optional Class A card (only on the
FX-64 panel)
Tie wrap mounts: Used to secure wires and to help maintain proper separation between power-
limited and nonpower-limited conductors
LED expander connector (J6): Provides a connection for the optional LED expander
Standby batteries: Provide secondary/standby power to the panel electronics in the absence of
primary power
Events with event messages
Table 44: Events with event messages
LCD Printer [1]
Active type reporting
Input smoke Alarm active SMK ACT
Input smoke verified Alarm active SMK ACT
Input heat Heat alarm HEAT ACT
Input heat rate of rise Heat alarm HEAT ACT
Input duct alarm Alarm active DUCT ACT
Input pull station Pull station alarm PULL ACT
Input waterflow Waterflow WFLW ACT
Input waterflow retard Waterflow WFLW ACT
CO alarm Gas CO active COAL ACT
Zone alarm Alarm active ALRM ACT
Zone waterflow Alarm active ALRM ACT
Alarm ON Alarm active ALRM ACT
Supervisory type reporting
Input duct alarm Supervisory DUCT ACT
CO supervisory Gas CO active COSU ACT
Zone supervisory Supervisory SUPV ACT
Input supervisory latching Supervisory SUPV ACT
Input supervisory nonlatching Supervisory SUPV ACT
