Safety thermostat RAK-TW.1000B
A
Safety thermostat RAK-TW.1000B
Part no. 7387 940
For safe limitation of the flow temperature of a heating circuit.
Standard delivery:
■ Safety thermostat RAK-TW.1000B
Controller, long-distance line
A
Sub-distributor
B
Bypass
C
Contact sensor QAD 21
D
Pump
E
Control valve
Part no. 7379 401
Via a long-distance line, a building is supplied with separate heat dis-
tribution. The long-distance line is controlled upstream according to
the demand of the heating circuits. The heating circuits of the separate
heat distribution must be controlled via the Ecotronic.
Standard delivery:
■ Button, long-distance line
■ Controller output for pump and control valve
■ Contact sensor QAD 21
Note
The long-distance line controller module can only be used while Köb
controller modules in the sub-distributor are also being used.
Control unit
(cont.)
