5.3 Accessories, flue system
Flue gas dust extractor
The flue gas dust extractor minimises dust emissions and is designed
as a multi cyclone with axial function. The dust extractor is fully insu-
lated and has three covers for cleaning.
The raw gas space is cleaned via the side cleaning cover. The clean
gas space is cleaned via the upper or back cleaning cover (unused fan
connection).
The ash box has a carriage and is connected to the dust extractor with
quick-action fasteners. It can easily be pulled out for emptying. The fan
can be installed either on the side or the top.
Note
The flue gas dust extractor is required for fuels with an increased per-
centage of fines (> 4 %).
Rated output kW 100 150 220 300 400 540
Part number 7423 662 7423 663 7423 664 7423 665
Standard delivery:
■ 1 flue gas dust extractor
■ 1 ash container hopper volume 90 litres
Note
Additional ash containers must be ordered separately.
Ash container 90 l, reserve
Part no. 7388 045
Installation accessories
(cont.)
34
PYROT
5
5822 516 GB
