3.4 Accessories for ECOTRONIC remote transfer
Fault message device, analogue with battery
Part no. 7387 994
Four different text messages are possible, as the fault message
modem has four independent digital inputs.
Standard delivery:
■ Analogue modem in control panel
■ Battery station (also works in event of a power failure)
To be carried out on customer side:
■ Electrical connection of the phone line to the modem
■ Configuration in accordance with the documentation
Export of operating data
Part no. 7388 038
Issue of relevant operating data and fault messages of the boiler sys-
tem as ASCII dataset via serial interface to higher control technology
on the customer side. If permitted by the control technology, the higher
control technology can change all adjustable parameters.
Standard delivery:
■ Interface at the control panel
■ Software module
■ MOD-BUS protocol
Note
Additional fault message device, analogue with battery station, part
no. 7387 994, possible
Additional visualisation, wired or wireless, part no. 7388 003, not
possible
Visualisation Pyrot - internal
Part no. 7387 839
With a data cable (max. 30 m), all data can be fed via the serial inter-
face RS 232 from the programming module to the PC. The current
operating data for the boiler system is displayed visually on a function
screen. All options for inputting values and functions and reading out
the operating conditions (exception: "Start boiler)" are shown. All oper-
ating data is archived cyclically and can be evaluated graphically in an
extremely simple way.
Note
The PC and data cable are not included in the price.
Standard delivery:
■ CD with visualisation software and installation instructions
Note
Requirements for on-site PC:
Operating system: Windows 98 / 2000 / XP
At least 50 MB free hard disk memory
At least 128 MB RAM
1 free serial interface per boiler
Visualisation, additional functions
Part no. 7387 821
Extension of visualisation [ECO VII] with the functions of additionally
enabled buttons (from F4). Additional functions include each heating
controller (heat source, heat consumer, solar) and automatic charging.
Every button function is shown on a separate function screen with all
options for entering values, reading out the operating conditions and
archiving. Price per piece for additionally enabled button on program-
ming module.
Standard delivery:
■ Extension of the visualisation software CD
Data cable to visualisation - internal
Part no. 7379 404
Data cable comprising:
■ D-SUB connector for connection between programming module and
data cable, soldered
■ 30 m data cable 3-pole (cut to length as required on site)
■ D-SUB connector with threaded fittings, 9-pole for connection to the
PC
Control unit
(cont.)
PYROT
23
5822 516 GB
3
