Extension of fill connector and return connector
Part no. 7388 056 Standard delivery:
■ Extension DN 100, length 700 mm, zinc-plated
■ Union nut for fitting
■ Clip for fastening
6.19 Fuel storage in on-site bunker (accessories)
Silo cover, manual FDM 2.9/1.3 m
Part no. 7387 782
Cover for secure sealing of openings for wood fuel delivery. The cover
is controlled manually with leg springs as an opening aid. The opening
has a fall protection grille to prevent anyone falling in when the cover
is open.
Note
For the filling process (opening, filling, closing), the local regulations
on accident prevention must be observed (e.g. enclosure, safety per-
sonnel).
Standard delivery:
■ Steel supporting structure
– Permissible load 250 kg/m²
– Sand-blasted
– Primed with zinc dust and painted
■ Welded fall protection grille with rod clearance 150 mm
■ Cover
– Surface, aluminium button plate
– Watertight, welded
■ Leg springs as opening aid
To be carried out on customer side:
■ Creating the ceiling recess with concrete collar
■ Seal between cover frame and supporting surface, concrete collar
■ Padlock to protect against incorrect operation
Design information
(cont.)
80
PYROT
6
5822 516 GB
