KOB PYROT - Centre discharge

7,92 mm
10,29 mm
6,02 mm
9,50 mm19,48 mm0,89 mm
27,72 mm
5,54 mm
1,98 mm
500
a
b
600
1230
50
> 1750
125
c
95,02 mm
0,48 mm
15,84 mm
(4000 - 12000)
d
50 - 150
A B
A - A
A A
49,44 mm
19,80 mm
0,79 mm
1,19 mm
19,68 mm
0,79 mm
42,36 mm
> 100
> 100
1500 - 2500 1500 - 2500
> 150
e
f
FS1
FR1
FZZ
FZD
D
C
E
C
A
K
DF
GH
Required order data for the above example:
Position Part no. Quantity Unit Designation
A
7387 978 2 pce Pushrod drive AS individual with hydraulic cylinder type L
B
7387 924 1 pce Cover for push floor screw conveyor (optional)
C
7387 952 2 pce Weld base, AS individual
D
7387 830 2 pce Weld base, bunker
E
Hydraulic compartment
F
Corresp. to length
See pricelist
2 pce Pushrod (incl. stop wedges)
G
Corresp. to dimensions
See pricelist
1 pce Push floor screw conveyor
H
7387 904 1 pce Version and drive, AQ standard
K
Corresponding boiler output
See pricelist
1 pce Hydraulic drive, ASH individual
Centre discharge
The drawing below is a general arrangement and should not be used
for construction design. A project-related drawing must be produced
for construction design.
Note
Only KÖB original weld bases are permissible for the pushrod drive.
Design information
(cont.)
PYROT
63
5822 516 GB
6
