KOB PYROT - Drive, trough screw conveyor, standard

58,32 mm
8,75 mm
6,40 mm
1,11 mm
2,32 mm
4,53 mm
5,10 mm
14,52 mm
1,47 mm
6,38 mm
2,32 mm
8,30°
500
176
< 10000
166
> 30
a/b
80
300
50
80
a
c
A
A
5,80 mm
8,12 mm
7,54 mm
7,31 mm
5,51 mm
c
d
b
e
g
f
A - A
13,77 mm
4,82 mm
14,51 mm
3,77 mm
7,54 mm
15,67 mm
7,54 mm
~ 500
166
500
l
k
h
e
A
A
B
A
Drive (optionally on the l.h. or r.h. side)
B
Inspection clearance
Trade name Trough screw conveyor
Type MF 150 MF 190 MF 250
Part no.: 7387 941 7387 873 7387 955
a mm 180x180 220x220 280x280
b mm 7180 7200 7200
c (Woodchips from forests) 20° 20° 20°
c (Pellets) 45° 45° 45°
d mm 140 280 380
e mm 220 260 352
f mm 216 256 317
g mm 150 190 250
h mm 130 130 154
k mm 260 260 350
l mm 540 540 665
Drive, trough screw conveyor, standard
Proven version for the trough screw conveyor with pulling drive and
discharge into a drop section. The system is driven via spur geared
motor and chain in dust-proof chain guard.
Standard delivery:
■ Drive unit with spur geared motor 3 x 400 V and chain drive
■ Inlet with light barrier for monitoring the fill level (overfill protection)
■ Discharge with inspection cover, safety limit switch and downpipe/
adaptor for the following conveyor device
Trade name Drive, trough screw conveyor
Part no.: 7387 971
Torque at screw conveyor Nm ~800 ~800 ~800
Diameter, screw conveyor mm 7150 7190 7250
Function Pulling Pulling Pulling
Max. length m 10 10 8
Max. boiler output (pellets) kW 2000 3200 -
Max. boiler output (woodchips from forests) kW 600 1500 2500
Pipe screw conveyor
Part no. 7387 990 for pipe screw conveyor D = 120 mm
Part no. 7387 962 for pipe screw conveyor D = 190 mm
Part no. 7387 928 for pipe screw conveyor D = 250 mm
Design information
(cont.)
