KOB PYROT - Pipe screw conveyor

The pipe screw conveyor is ideal for conveying pourable wood fuels
and/or in the case of steep ascending inclines.
Standard delivery:
■ Pipe screw conveyor according to the project drawing
Note
Article price per m.
Total price: length L in m x article price.
Trade name Pipe screw conveyor
Part no.: 7387 990 7387 962 7387 928
Diameter of the screw conveyor max. mm 120 190 250
Trade name Pipe screw conveyor
Type MR-L120 MR-L190 MR-L250
Part no.: 7387 990 7387 962 7387 928
a mm 140 280 380
b mm 150x150 220x220 280x280
c mm 140 220 324
d mm 120 190 250
Angle of inclination max. with pushing screw conveyor
e mm - 90° 90°
Angle of inclination max. with pulling screw conveyor
e mm 65° 65° 65°
f mm
7150 7200 7200
g mm 140 280 380
h mm 540 540 665
k mm 130 130 154
l mm 260 260 350
Design information
(cont.)
