KOB PYROT - 6.14 Fuel discharge by means of push floor (sizing); Number and length of the pushrods with a maximum dumping height

Version and drives
Funnel discharge AP-11 AP-12
AP-Z02
*10
Part no. 7837 794 7837 958 7388 042
a m 6.0 7.5 7.5
b mm 2205 3005 3005
c mm 708 1030 1030
d mm 282 310 -
e Nm 431 469 -
Additional outlet flange
Part no. 7387 520
Additional connection option for conveyor devices to discharge casing
for twin-boiler system.
Funnel, large
Part no. 7388 042
Surcharge for a funnel diameter of 3000 mm. Note
In the case of funnel discharge AP-12, a funnel diameter of 3000 mm
is required.
6.14 Fuel discharge by means of push floor (sizing)
Number and length of the pushrods with a maximum dumping height
Applies to pushrods for pushrod drive (AS) individual and for the push-
rod with discharge function of the AS-twin (standard version). Permis-
sible dumping heights below are maximum values and should not be
exceeded.
Special version as individual rod with a width of up to 3.00 m possible
on request.
Max. permissible dumping height and length of the pushrods in S200
Trade name Pushrod
Type AS-2.50 AS-2.25 AS-2.0 AS-1.75 AS-1.5
Part no.: 7387 992 7387 995 7387 836 7387 956 7387 989
Dumping height with length:
12 m 3.1 3.6 4.1 4.9 5.8
10 m 3.9 4.6 5.3 6.3 7.4
8 m 5.3 6.1 7.0 8.4 9.8
6 m 7.5 8.6 9.8 12.3 14.9
Max. permissible dumping height and length of the pushrods in S350
Trade name Pushrod
Type AS-2.50 AS-2.25 AS-2.0 AS-1.75 AS-1.5
Part no.: 7387 992 7387 995 7387 836 7387 956 7387 989
Dumping height with length:
10 m 2.6 3.0 3.5 4.1 4.8
8 m 3.4 4.0 4.55 5.4 6.4
6 m 4.9 5.6 6.4 8.0 9.7
Max. permissible dumping height and length of the pushrods in S450
Trade name Pushrod
Type AS-2.50 AS-2.25 AS-2.0 AS-1.75 AS-1.5
Part no.: 7387 992 7387 995 7387 836 7387 956 7387 989
Dumping height with length:
10 m 2.1 2.4 2.7 3.2 3.8
8 m 2.7 3.1 3.6 4.2 5.0
6 m 3.8 4.4 5.0 6.2 7.5
*10
Option for article AP-11. Required for AP- 12
Design information
(cont.)
