KOB PYROT - Slot discharge, for pulling

FZD Maximum pressure force on the weld base for pushrod drive
FZZ Maximum tensile force on the weld base for pushrod drive
Number of pushrods 1 2 3
FS mm 1x FS1 1x FS1 2x FS1
FR mm 1x FR1 1x FR1 110
FS1 FR1 FZZ FZD FG1 FM1 Z
Standard version
AS-001/2
160 kN 130 kN 362 kN 484 kN 12 kN 100 kN 125 mm
Heavy version
Y article
240 kN 195 kN 542 kN 722 kN 15 kN 150 kN 150 mm
Slot discharge, for pulling
The drawing below is a general arrangement and should not be used
for construction design. A project-related drawing must be produced
for construction design.
Note
Only KÖB original weld bases are permissible for the pushrod drive.
Specification
Slot discharge, for pulling Screw conveyor
D = 190 mm
Screw conveyor
D = 250 mm
a mm 650 700
b mm 380 430
c mm 350 400
d For max. dumping height, see page 60 For max. dumping height, see page 60
e mm > 3200 > 3200
f mm 1500-2500 1500-2500
Design information
(cont.)
