5.1 Boiler safety equipment
Thermally activated safety valve 100 °C
Part no. 7387 405
Standard version for response temperature approx. 100 °C, connec-
tion R . ¾
Standard delivery:
■ Thermally activated safety valve incl. sensor well
Note
We recommend the thermally activated safety valve even if there is
no need to use it in accordance with the local safety regulations.
Thermally activated extinguishing valve ½”, 50-90 °C
Part no. 7387 521
Thermally opening extinguishing valve with adjustable opening tem-
perature for on-site connection to a pressurised water line or an extin-
guishing water container.
Standard delivery:
■ Extinguishing valve Danfoss AVTA, adjustable 50-90 °C with dirt trap
Supply screw conveyor two-level
Part no. 7387 831
Version with two-level supply screw conveyor. This enables operation
matched to the fuel used. It is optimised for shavings/woodchips (high
level) on the one side and for pellets (low level) on the other.
Standard delivery:
■ Geared motor, supply screw conveyor, pole-changing 750/
300 rpm
■ Starttec for geared motor, pole-changing
■ Software module in the control unit
Insulation, flue gas recirculation line
High temperature-resistant insulation 35 mm thick made from mineral
wool with aluminium lamination and side adhesive strips for straight
elements of the flue gas recirculation line. Aluminium foil adhesive
strips for the faces are also supplied.
Designation Part no.
Insulation, flue gas recirculation line, per m, DN
80
7387 421
Insulation, flue gas recirculation line, per m, DN
125
7388 023
Installation accessories
32
PYROT
5
5822 516 GB
