KOB PYROT - Slot discharge with fill function

Required order data for the above example:
Position Quantity Unit Designation
A
2 pce Pushrod drive AS individual with hydraulic cylinder type K
B
2 pce Weld base, bunker
C
Cover, centre discharge
D
1 pce Push floor screw conveyor
E
4 pce Pushrod (incl. stop wedges)
F
1 pce Version and drive, AQ standard
G
Hydraulic compartment
H
1 pce Hydraulic drive, ASH individual
K
2 pce Weld base, AS individual
Slot discharge with fill function
The drawing below is a general arrangement and should not be used
for construction design. A project-related drawing must be produced
for construction design.
Note
Only KÖB original weld bases are permissible for the pushrod drive.
Specification
Slot discharge with fill function Screw conveyor
D = 190 mm
Screw conveyor
D = 250 mm
a mm 650 700
b mm 380 430
c mm 350 400
d Charging chute
e For max. dumping height, see page 60
f mm > 3200 > 3200
Design information
(cont.)
