KOB PYROT - Price Reduction Net Compressed Air on Site

■ Valves fully wired on terminal strip
■ Software module in the control unit
To be carried out on customer side:
■ Provision of a socket 400 V / 16 A
■ Connector for compressor 400 V / 16 A
Specification
Rated output kW 100 150 220 300 400 540
Part no.: 7423 666 7423 667 7423 668 7423 669 7423 670 7423 671
Number of zones/valves pce 3 4 4 4 5 6
Size of valves G 1 1 1 1 1 1
Max. air consumption under full load l/h 1300 1300 2500 2500 3300 4500
Price reduction net compressed air on site
Part no. 7388 288
This eliminates the need for the compressor listed in "Cleaning pneu-
matic". The compressor provided on the customer side must supply at
least the specific quantity and quality of the air and have an adjustable
pressure regulator and protection against hose break (e.g. runtime
limiter).
The compressor must also meet the following minimum require-
ments:
■ Compressor (rotation compressor) for local applications
– Supply output 160 l/min
– Container 90 l
– Pressure max.10 bar
– Motor 1.5 kW
–
1450 rpm
– 3 x 400 V
– Incl. pressure regulator and pressure switch
– Sound level 68 dB(A)
Installation accessories
(cont.)
38
PYROT
5
5822 516 GB
