Fall protection grille 120 for FDH
Fall protection grille for corresponding bunker cover in several ele-
ments to prevent anyone falling in when the cover is open. Each ele-
ment is prepared for installation of a shaker motor (shaker motor for
additional charge).
Standard delivery:
■ Support profile for installation in ceiling recess
■ Fall protection grille in several elements, mesh size: 200 x 120 mm
Specification
Fall protection grille, type 120 for FDH 4.0/2.4 FDH 5.5/2.4 FDH 7.0/2.4 FDH 8.5/2.4
Part no. 7387 914 7387 817 7388 014 7387 922
Quantity pce 2 2 3 4
Weight per pce kg 117 161 133/141 124/120
Fall protection grille 200 for FDH
Fall protection grille to prevent anyone falling in when the cover is
open. Suitable for corresponding bunker cover in several elements.
Each element is prepared for installation of a shaker motor (shaker
motor for additional charge).
Standard delivery:
■ Support profile for installation in ceiling recess
■ Fall protection grille in several elements, mesh size: 200 x 200 mm
Specification
Fall protection grille, type 200 for FDH 4.0/2.4 FDH 5.5/2.4 FDH 7.0/2.4 FDH 8.5/2.4
Part no. 7387 910 7387 824 7387 930 7387 983
Number of elements pce 2 2 3 4
Weight per pce kg 104 143 118/125 110/106
Bunker cover, movable FDB
Cover for secure sealing of openings let into travel planes for wood
fuel delivery. The surface of the cover is flush with the travel plane.
The sub-structure has a drip channel. The cover is controlled manually
using a hydraulic cylinder. The silo cover is prevented from falling shut
in the event of a hose break.
Standard delivery:
■ Supporting structure:
Perm. wheel load: FDB 3.0/2.0: 7.5 t; FDB 3.8/2.4 and FDB 3.2/3.2:
10.0 t; steel, sand-blasted, primed with zinc dust and painted
■ Cover surface:
For filling with asphalt or concrete on the customer side
■ Sub-structure:
Has drip channel and two drain connectors NW 100
■ Hydraulic cylinder:
With hinge lug connection, pipe break protection, mount and
hydraulic hoses 1 m long
To be carried out on customer side:
■ If the travel surface is sloping, the water flowing to the cover must
be drained away upstream of the cover frame by means of a drain
channel
■ Drain line for rainwater, channel heating
■ Seal between cover frame and supporting surface of cover frame
■ Filling of the cover surface with a bitumen layer and asphalt or con-
crete, watertight design (max. permissible weight of the fill 2200 kg/
m
3
)
Design information
(cont.)
PYROT
83
5822 516 GB
