Specification
Bunker cover, movable FDB FDB 3.0/2.0 m FDH 3.8/2.4 m FDH 3.2/3.2 m
Part no. 7387 850 7387 793 7387 974
a mm 3000 3800 3200
b mm 2110 2510 3310
c mm 2000 2400 3200
d mm 3150 3950 3350
e mm 2530 2930 3730
f mm 2150 2550 3310
Weight, cover, FDB kg 1520 2360 2680
Max. permissible wheel load t 7.5 10 10
Fall protection grille, 120 for FDB
Fall protection grille to prevent anyone falling in when the cover is
open. Suitable for corresponding bunker cover in several elements.
Each element is prepared for installation of a shaker motor (shaker
motor for additional charge).
Standard delivery:
■ Support profile for installation in ceiling recess
■ Fall protection grille in several elements
■ Mesh size:
200 x 120 mm
Specification
Fall protection grille, type 120 for FDB 3.0/2.0 m FDH 3.8/2.4 m FDH 3.2/3.2 m
Part no. 7387 889 7388 016 7387 868
Number of elements pce 2 2 2
Weight per pce kg 130 205 230
Fall protection grille, 200 for FDB
Fall protection grille to prevent anyone falling in when the cover is
open. Suitable for corresponding bunker cover in several elements.
Each element is prepared for installation of a shaker motor (shaker
motor for additional charge).
Standard delivery:
■ Support profile for installation in ceiling recess
■ Fall protection grille in several elements
■ Mesh size:
200 x 200 mm
Specification
Fall protection grille, type 200 for FDB 3.0/2.0 m FDH 3.8/2.4 m FDH 3.2/3.2 m
Part no. 7387 798 7387 801 7388 019
pce 2 2 2
Weight per pce kg 120 180 210
Shaker motor for fall protection grille
Part no. 7387 810
The shaker motor sets the fall protection grille in an oscillating motion.
This prevents the delivered fuel from bridging the fall protection grille
and therefore ensures a steady material flow during filling.
Standard delivery:
■ Shaker motor, 3 x 400 V incl. control, thermal protection and instal-
lation material
■ Key switch
To be carried out on customer side:
■ Electrical connection of shaker motor and key switch
Note
One shaker motor is required per fall protection grille element. In addi-
tion, when using shaker motors, a large control panel must be included
in the plans.
Hydraulic drive, bunker charging cover, ASH
Part no. 7388 856
The hydraulic drive is used exclusively for actuating a bunker cover,
which is opened hydraulically. The cover is opened by the hydraulic
cylinder when the key switch button is pressed. When the key switch
button is released, the load holding valve fixes the cover in position.
Standard delivery:
■ Hydraulic drive comprising:
– Gear pump 4 l/min incl. motor 1.5 kW 3 x 400 V
– Oil container 12 l, non-return valve
– Pressure limiter valve
– Pressure diverter valve
– Return filter
– Oil level indicator
– Pressure gauge
– Shut-off valve
– Oil filling
