A Installation position, horizontal (version 1)
B Installation position, sloping (version 2)
C Finished floor, concrete-lined (concrete block out for recessed
installation)
A
Finished floor
B
Seal installation opening with fire-retardant panel
C
Base (height adjustable)
D
Axis, screw conveyor
E
Axis, agitator
F
Sub-structure
G
Building floor
H
Centre, agitator
K
Concrete block out (for recessed installation)
Fuel-specific limits
Maximum fill level
Pellets S 650 m 4.5
Briquettes S 350 m 6.0
Woodchips from forest S
250
m 8.0
Boiler output max.
Pellets S 650 kW 2000
Briquettes S 350 kW 720
Woodchips from forest S
250
kW 720
a Angle of inclination max.
Pellets S 650 6°
Briquettes S 350 0°
Woodchips from forest S
250
15°
Note
For pellets, the cover panels part no. 7387 895 are required.
Discharge screw conveyor AH for horizontal discharge
Part no. 7387 603
The fuel is moved by the horizontal discharge agitator arms into the
conveyor channel, which is open across the entire bunker length. Out-
side the bunker, the screw conveyor channel is sealed.
Standard delivery:
■ Conveyor channel running through the entire system with specially
matched discharge screw conveyor
Note
Article price per m.
The max. length is 10 m. Total price:
Total length L in m (max. 10) x individual price.
Protective panel AH for bunker
Part no. 7387 985
Metal cover to protect against damage to the bunker wall caused by
the agitator arms. Mounting on the internal wall of the silo.
Standard delivery:
■ Protective panel, painted
Length and number matched to the project
■ Rawl plugs and screws
Cover panel AH for pellets
Part no. 7387 895
Metal cover of the open screw conveyor area to reduce the inlet cross
section.
Note
Observe the following when changing the fuel:
1. Changeover: forest woodchips to pellets:
Before filling the silo with woodchips, remove the cover panels from
the discharge screw conveyor.
2. Changeover: pellets to forest woodchips:
The discharge system is to be extended by means of cover panels.
Standard delivery:
■ Cover panel, painted
Length and number matched to the project
■ Screws
Design information
(cont.)
58
PYROT
6
5822 516 GB
