Flue pipe, L = 1000 mm
Version: black, without insulation
Flue pipe, L = 1000 mm Part no.
D = 200 mm 7388 233
D = 250 mm 7388 194
D = 300 mm 7388 148
D = 350 mm 7387 425
6.22 Sound insulation
Braces
To avoid the transmission of structure-borne noise during the opera-
tion of the fuel transportation equipment, the braces and the anchors
of the relevant conveyor device are placed on high quality Sylomer
bases (plastic anti-vibration mounts for noise attenuation) or anchored
with a Sylomer support and a fixing plate in the building structure. The
anchors with heavy load anchors are separated from the braces with
Sylomer washers.
Standard delivery:
■ Sylomer washer
■ Sylomer support
■ Sylomer base
■ Fixing plate for the braces of the relevant equipment
Trade name Sound insulation, braces
Type Discharge
screw con-
veyor
Supply
screw con-
veyor
Insert Spring core
discharge
Horizontal
discharge
Ash removal Flue gas
dust extractor
Part no.: 7419 991 7419 992 7419 994 7419 996 7419 997 7419 998 7419 999
Note
■ For each different means of fuel transportation, the sound insulation
article should be used once. Example: 1 AH + 1 sound insulation
AH-AS.
■ Installation room characteristics relating to the physical building
structure largely determine the transmission of structure-borne noise
in the building. It is important to note that the specified measures do
not offer full sound insulation.
■ Building related measures (brick openings, fire barriers, floating
screeds, etc.) must be coordinated with structural engineers and
architects and are not part of standard delivery and therefore not
within our area of responsibility.
Appendix
7.1 Sizing the expansion vessel
In accordance with EN 12828, water heating systems must be equip-
ped with a diaphragm expansion vessel. The size of the expansion
vessel is subject to the heating system specification and should be
checked in each case.
Quick selection table for calculating the vessel size V
n
Safety valve
p
sv
bar 3.0 V
n
Pre-charge
pressure
bar 1.0 1.5 1.8
litres
System vol-
ume V
A
litres 220 — — 25
340 200 — 35
510 320 200 50
840 440 260 80
1050 540 330 100
1470 760 460 140
2100 1090 660 200
2630 1360 820 250
3150 1630 990 300
4200 2180 1320 400
5250 2720 1650 500
Design information
(cont.)
90
PYROT
7
5822 516 GB
