Drive, push floor screw conveyor, standard
Part no. 7387 904
Standard version for push floor screw conveyor with pulling drive and
discharge into a drop section. The system is driven via spur geared
motor and chain in dust-proof chain guard.
Standard delivery:
■ Drive unit with spur geared motor 400 V and chain drive
■ Light barrier across the entire open area for monitoring the fill level
(overfill protection)
■ Discharge with inspection cover, safety limit switch and downpipe/
adaptor for the following conveyor device (not required in pushing
version)
Drive, push floor screw conveyor, standard
Part no. 7837 904
Torque at screw conveyor Nm ~800 ~800 ~800
Push floor screw conveyor Type AQ-L150 AQ-L150 AQ-L190
Function, push floor screw conveyor Pulling Pushing Pulling
Max. length, push floor screw conveyor m 10 8 10
Max. boiler output with woodchips kW 300 300 1250
Drive, push floor screw conveyor, higher-power
Part no. 7387 866
Special, powerful version of the push floor screw conveyor for more
difficult applications (high pump rate and/or pushing function). The
system is driven via a more powerful version of a spur geared motor,
bearing and chain in dust-proof chain guard.
Standard delivery:
■ Drive unit in powerful version and additional axial bearing with push-
ing function with spur geared motor 400 V and chain drive; matching
and control on project basis
■ Light barrier across the entire open area for monitoring the fill level
(overfill protection)
■ Discharge with inspection cover, safety limit switch and downpipe/
adaptor for the following conveyor device (not required in pushing
version)
Drive, push floor screw conveyor, higher-power
Part no. 7837 866
Torque at screw conveyor Nm ~1200 ~1200 ~1200
Push floor screw conveyor Type AQ-L190 AQ-L250 AQ-L250
Function, push floor screw conveyor Pulling Pushing Pulling
Max. length, push floor screw conveyor m 10 8 10
Max. boiler output with chippings kW 1500 2500 2500
Cover, push floor screw conveyor
Part no. 7387 924
Cover for the open trough of the push floor screw conveyor and the
bunker slot. The cover is fitted to the front bunker panel and can be
opened via a hinge. It helps to protect maintenance personnel against
contact.
Standard delivery:
■ Cover of the push floor screw conveyor with wall mounting bracket
and hinge according to project drawing
■ Limit switch for emergency stop of the push floor and the push floor
screw conveyor when opening the cover
Note
Article price per m.
Total price: length A in m x article price [A = width of bunker].
6.16 Charging the boiler with fuel
Trough screw conveyor
Part no. 7387 941 for trough screw conveyors D = 150 mm
Part no. 7387 873 for trough screw conveyor D = 190 mm
Part no. 7387 955 for trough screw conveyor D = 250 mm
The trough screw conveyor is an extremely reliable means of trans-
portation for all granulated wood fuels. Observe the restriction in the
angle of inclination.
Standard delivery:
■ Trough screw conveyor according to the project drawing
Note
Article price per m. Total price: length L in m x article price
Design information
(cont.)
