Additional heat source controlled with a directional control valve
for oil/gas boiler
L
Additional heat source controlled with a directional control valve
for
- Oil/gas boiler
- Electric heater
Sizing recommendation
Trade name Pyrot rotation combustion
Rated output kW 100 150 220 300 400 540
Boiler circuit NW 40 NW 50 NW 50 NW 65 NW 80 NW 80
Thermally activated safety valve TS-131 pce 1 1 1 1 1 1
Required water flow rate at 2.5 bar l/h 620 915 1230 1500 1880 2266
Cylinder capacity l 1500 1500 2200 2500 3200 4300
Supply line ZL R ¾ ¾ ¾ ¾ ¾ ¾
Drain line AL R 1 1 1 1 1 1
Safety valve type SV 68M R 1 1 1 1 ¼ 1 ¼ 1 ½
Safety line SL NW 32 NW 40 NW 40 NW 50 NW 50 NW 65
6.6 Electrical installation
Electrical installation should be carried out in accordance with the wir-
ing diagram. In the vicinity of hot parts (flue gas fan, flue pipe), cables
must be routed in steel pipes for temperature protection and appro-
priate clearances.
The cable entries for the motors and equipment should be dust-proof
and unstressed.
Positioning of the programming module and control panel
The programming module should be installed by the electrical com-
pany responsible for installation in a place that is easily accessible for
operation. Optimal positioning of the control panel can minimise cable
lengths and therefore reduce costs. The location of the programming
module and control panel should be selected so that the negative
influence caused by thermal radiation (boiler front panel, boiler back
panel with flue gas collector and flue gas fan, as well as flue pipe) and
exposure to dust during cleaning is minimised.
The ambient temperature of the control panel (approx. 10 cm away
from the control panel) when operating the system must not exceed
40 °C. In case of doubt, the control panel should preferably be located
outside the boiler room near to the boiler room door.
Note
The regulations of the local power supply utility must be observed.
6.7 Safety equipment
Expansion
In the case of sealed expansion, the pre-charge pressure of the expan-
sion vessel should be equal to the max. system height plus 0.2 bar.
Extinguishing facilities
A water extinguishing facility is required on the supply screw conveyor.
This facility is used in the event of a fault (e.g. power failure) to safely
prevent burn-back. For safety reasons and in order to avoid damage
caused by flooding, it is not advisable to connect the extinguishing
facility directly to the water mains.
This extinguishing facility is equipped with an extinguishing water con-
tainer 25 l with float switch and an adjustable Danfoss extinguishing
valve. In accordance with TRVB 118, the container should be equipped
with fill level monitoring. The PYROT rotation combustion system
automatically switches off in case of a water shortage. In the case of
excessive temperature, the supply screw conveyor is safely flooded
but to a limited extent.
Design information
(cont.)
PYROT
47
5822 516 GB
