Visualisation, externally via modem (connected with cable)
Part no. 7387 792
Package for the transmission of relevant data to an EDP workstation
(internal and/or external) for the visualisation, remote maintenance
and operating data archiving of the PYROT boiler system. Hardware
and software are integrated into the Ecotronic control unit. All adjust-
able parameters can be changed from the EDP workstation.
Standard delivery:
■ Industrial PC with interfaces for screen, keyboard and PC mouse for
EDP workstation close to boiler room
■ Analogue modem in control panel
■ Windows operating system, remote maintenance software pcAny-
where and visualisation/archiving software installed and tested on
the industrial PC.
Images on the screen:
■ Cross-section image of boiler, 3D with display fields
■ Installation scheme for heat source with display fields
■ Table of parameters (with change option)
To be carried out on customer side:
■ EDP workstation for remote maintenance together with modem,
installation of pcAnywhere and modem is to be set up independently
by the customer
Note
Additional fault message device, analogue with battery station, part no.
7387 994, possible
Additional export of operating data, part no. 7388 038, not possible
Control unit
(cont.)
24
PYROT
3
5822 516 GB
