Kollmorgen AKD

Ethernet IP with RSLogix | 9 Appendix B: Parameter Listing
Instance Parameter DataSize Data Type
638 AOUT2.ISCALE 4 Byte Float
639 AOUT2.MODE 2 Byte Integer
640 AOUT2.OFFSET 4 Byte Signed Float
641 AOUT2.PSCALE 8 Byte (truncated to 4 Byte) Position
643 AOUT2.VALUE 4 Byte Signed Float
645 AOUT2.VALUEU 4 Byte Signed Float
647 AOUT2.VSCALE 8 Byte (truncated to 4 Byte) Velocity
649 BODE.IFLIMIT 4 Byte Signed Float
650 BODE.IFTHRESH 4 Byte Signed Float
651 BODE.VFLIMIT 4 Byte Signed Float
652 BODE.VFTHRESH 8 Byte Signed (truncated to 4 Byte Signed) Velocity
654 DIN10.STATE 1 Byte Integer
655 DIN11.STATE 1 Byte Integer
656 DIN21.FILTER 2 Byte Integer
657 DIN21.INV 1 Byte Integer
658 DIN21.MODE 2 Byte Integer
659 DIN21.PARAM 8 Byte Signed (truncated to 4 Byte Signed) Varies
661 DIN21.STATE 1 Byte Integer
662 DIN22.FILTER 2 Byte Integer
663 DIN22.INV 1 Byte Integer
664 DIN22.MODE 2 Byte Integer
665 DIN22.PARAM 8 Byte Signed (truncated to 4 Byte Signed) Varies
667 DIN22.STATE 1 Byte Integer
668 DIN23.FILTER 2 Byte Integer
669 DIN23.INV 1 Byte Integer
670 DIN23.MODE 2 Byte Integer
671 DIN23.PARAM 8 Byte Signed (truncated to 4 Byte Signed) Varies
673 DIN23.STATE 1 Byte Integer
674 DIN24.FILTER 2 Byte Integer
675 DIN24.INV 1 Byte Integer
676 DIN24.MODE 2 Byte Integer
677 DIN24.PARAM 8 Byte Signed (truncated to 4 Byte Signed) Varies
679 DIN24.STATE 1 Byte Integer
680 DIN25.FILTER 2 Byte Integer
90 Kollmorgen | kdn.kollmorgen.com | November 2018
