AU-DDR Advanced U-Arm System with
Dynamic Digital Radiography (KDR AU DDR)
7. Use the up and down arrows to manually adjust your techniques (kVp, mA, ms, mAs).
8. Position your patient and shoot your rst image.
NOTE: The radiation symbol will automatically jump to the next view while the image is processing.
NOTE: If you have a licensed U-arm positioner, once the radiation symbol has moved to the next view, you will be
able to hit MOVE on the remote or positioner console, and the U-arm positioner will move to the next position.
9. For a Sedecal generator with a door interlock connected, if the door is open or the interlock is not otherwise en-
gaged, an image will be displayed showing an open door.
10. Continue the procedure until you have acquired all the images needed.
IV. SOFTWARE
