PAGE 15 - TRACK: MODE
This page lets you set the polyphony mode for each track.
Use the TRACK SELECT button to switch between Song
tracks 1-8, Song tracks 9-16, and back again.
Parameters
Drum This is a Drum/Percussion track. No Master or
Octave Transpose applies to this track. You can
set a different volume (“Page 14 - Track: Easy
edit” on page 13-12) and a separate output
(“Page 13 - Audio Output Configuration” on
page 16-6) for each class of percussive instru-
ments.
Poly Tracks of this kind are polyphonic, i.e. they can
play more than one note at the same time.
Mono Tracks of this kind are monophonic, i.e. each
new note stops the previous note.
Mono Right A Mono track, but with priority assigned to
the rightmost (highest) note.
PAGE 16 - TRACK: INTERNAL/EXTERNAL
This page lets you set the Internal or External status for each
track. It is very useful to let a Song track drive an external
expander.
Use the TRACK SELECT button to switch between Song
tracks 1-8, Song tracks 9-16, and back again.
Parameters
Internal The track plays the sounds generated by the
internal sound engine. It does not play an
external instrument connected to the MIDI
OUT.
External The track plays an external instrument con-
nected to the MIDI OUT. It does not play the
internal sounds, thus saving polyphony.
When a track is set to “External”, a strings of
transmitted Control Change and Program
Change data is shown instead of the Program
name assigned to the track. In the following
example, CC#0 is the Control Change 0 (Bank
Select MSB), CC#32 is the Control Change 32
(Bank Select LSB), PC is the Program Change.
Both The track plays both the internal sounds and
an external instrument connected to the MIDI
OUT.
Poly Poly
Poly Poly
Poly Poly
Poly Poly
Track:Mode
Poly Poly
Drum Poly
Drum Poly
Poly Poly
Track:Mode
Both Both
Both Both
Both External
Both Both
Track:Int/Ext
Both Both
Both Both
Both External
Both Both
Track:Int/Ext
121- 3- 0
CC#0
CC#32
PC
