20. EFFECTS
Pa80 is equipped with four powerful Effect Processors. You
can send them the internal tracks, or any signal entering the
Audio Inputs.
DIAGRAMS
The following instructions show the signal path diagram for
each of the effect types. The signal coming from the tracks
(Send) is mono. Before entering an effect processor, it is split
in two “wires” (Left and Right), and processed in stereo. The
signal is then output in stereo from the effect processor, and
sent to the Mix output (Left&Right, the heaphones or the
internal speakers).
DYNAMIC MODULATION SOURCES
When the symbol is encoutered, a Dynamic Modula-
tion can be applied to the corresponding parameter. The fol-
lowing table shows the available modulation sources.
Filter and dynamics control effects
000: No Effect
Select this option when you do not use any effects. When this
option is selected, the effect is muted.
001: Amp Simulat
(Stereo Amp Simulation)
This effect simulates the frequency response characteristics of
guitar amplifiers. It is also effective for organ and drum
sounds.
Modulation source Note
Off No modulation
Gate1
Gate1+Dmpr
Gate2
Gate2+Dmpr
Note Nr Note Number
Velocity Note Velocity
ATouch After Touch
JS X Joystick Left/Right
JS+Y: CC#01 Joystick Forward
JS-Y: CC#02 Joystick Backward
MIDI(CC#04)
MIDI(CC#12)
MIDI(CC#13)
MIDI(CC#16)
MIDI(CC#18)
MIDI(CC#17)
MIDI(CC#19)
Effect Block
Diagram
Send
Left
Right
MIDI(CC#20)
MIDI(CC#21)
Damper: #64
Prta.SW: #65 Portamento Switch
Sostenu: #66 Sostenuto Pedal
MIDI(CC#80)
MIDI(CC#81)
MIDI(CC#82)
MIDI(CC#83)
Tempo
FILTER/DYNAMIC
a
Amplifier Type
Selects the type of guitar amplifier
SS, EL84, 6L6
b
Wet/Dry Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
Src Off...Tempo
Selects the modulation source of the effect balance
Amt
Sets the modulation amount of the effect balance
–100...+100
Modulation source Note
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Amp Simulation Filter
Amp Simulation Filter
