internal tone generator. Therefore, the Scale
will be applied before transposition. For exam-
ple, if you altered an E, and then set the Master
Transpose to +1, the altered key will still be E
(that will play an altered F).
PAGE 3 - VIDEO INTERFACE
If a Video Interface Board is fitted into your Pa80, use this
page to program it.
System
Selects the video standard (PAL or NTSC).
Character
Select the character size (Big or Small).
Colors
Selects a color set for the lyrics and background.
1…6 Color set.
X/Y control
These parameters lets you adjust the image position on the
external monitor.
PAGE 4 - ASSIGNABLE PEDAL/FOOTSWITCH,
ASSIGNABLE SLIDER, EC5
This page lets you program the Assignable Pedal/Footswitch,
the Assignable Slider, and the EC5 multiswitch.
See page 21-1 for a list of the assignable functions. The first
functions are switch-type functions, while the remaining
(starting from Master Volume) are continuous-like func-
tions.
P/S (Pedal/Switch)
Continuous pedal, or footswitch, connected to the ASSIGN-
ABLE PDL/SW connector.
Sld (Slider)
Function assigned to the ASSIGNABLE SLIDER on the front
panel.
EC5-A…E
Each of the switches of a KORG EC5 multiswitch.
Damper Pol. (Damper Polarity)
Polarity of the Damper pedal.
Pedal/Sw. Pol. (Pedal/Footswitch Polarity)
Polarity of the Assignable pedal or footswitch.
PAGE 5 - MIDI SETUP
MIDI channels can be automatically configured by selecting a
MIDI Setup. Each of them assigns the best values to various
MIDI parameters, to allow an easier connection with a par-
ticular MIDI controller.
Note: After selecting a MIDI Setup, you can apply any changes
to each channel’s settings. To store the changes in memory, press
WRITE and save the Global in memory.
See “MIDI” on page 8-1 for more information on using the
MIDI Setups.
Default This a default setting. It is suitable both for
programming on an external sequencer, and
for playing Pa80 with a master keyboard.
Master Kbd Select this setting when you are connecting a
mute master keyboard.
Sequencer 1 This setting is for playing a Song (Sequencer 1)
with an external instrument sounds, or for lis-
tening to a Song performed by an external
sequencer using Pa80 as a sound generator.
Each track (S1 Tr1-16) corresponds to a MIDI
channel with the same number (1-16).
Sequencer 2 As above, but with Sequencer 2.
Accordion 1…3
Select one of these settings when connecting a
MIDI Accordion.
Ext.Seq This setting is for programming a Song on an
external sequencer.
PAGE 6 - MIDI CONTROLS
This page lets you program general MIDI parameters.
Local
The Local parameter turns the keyboard on or off.
Scale
Tone
generator
Transpose
System:PAL
Character:Big
Colors:1
Xctl:16 Yctl:48
Gbl:Video IF
P/S:Soft |
Sld:M.Volume
EC5-A:Off
EC5-B:Off |
Gbl:P/Sw-Sld-EC5
Default Accordion1
Master Kbd Accordion2
Sequencer1 Accordion3
Sequencer2 Ext.Seq
Gbl:Midi Setup
Local:On
Clock:Internal
Clock Send:Off
To Host rate:31.25k-Mac
Gbl:MIDI Ctl
