Note: With some effect types, sending the Audio Inputs to the C
and D Internal FX processors may cause some residual noise to
become evident. Use these parameters to zero the send level. As
an alternative, you can select the Direct audio path (see “Input
1/2” on page 16-7).
PAGE 16 - INTERNAL FX CONTROLS
In this page you can assign an Internal FX parameter to a
physical controller. The settings on this page are only effec-
tive if you select the IntFXSwitch or IntFXCtl options on
“Page 4 - Assignable Pedal/Footswitch, Assignable Slider,
EC5”.
AssignPdl (Assignable Pedal)
Internal FX parameter assigned to the Assignable Pedal.
AssignSld (Assignable Slider)
Internal FX parameter assigned to the Assignable Slider. For a
list of assignable parameters, see the parameter list for the
Assignable Pedal above.
AssignSw1 (Assignable Switch 1
AssignSw2 (Assignable Switch 2
Internal FX parameters assigned to the Assignable Foot-
switch, EC5 pedal or Pad.
PAGE 17 - VOCAL/GUITAR MODE
In this page you can select the Vocal/Guitar Processor Board
(VHG1) operating mode (if installed). The pedal and slider
settings on this page are only effective if you select the Vcl/
GtrSwitch or IntFXCtl options on “Page 4 - Assignable Pedal/
Footswitch, Assignable Slider, EC5”.
Note: The “Input 1/2” parameter must be set to “1/2 Vocal/
Gtr”. At least one channel should be sent to the Vocal/Guitar
Processor Board.
Mode
Selects the operating mode of the Vocal/Guitar Processor
Board (VHG1). Parameters on the following pages are differ-
ent, according to the selected mode.
Vocal Select this mode when you are connecting a
microphone to the Audio Inputs. While in this
mode, you are supplied with vocal effects and a
Vocal Harmonizer. The available fixed effects
are Harmonizer, Tone, Compressor; plus, there
Parameter Meaning
Input1 Vol Volume of the Input 1.
Input2 Vol Volume of the Input 2.
Input 1/2 Vol Volume of the Inputs 1 and 2.
FX C Send1 Send level of the Input 1 to the C FX
processor (reverb).
FX C Send2 Send level of the Input 2 to the C FX
processor (reverb).
FX C Send1/2 Send level of the Inputs 1 and 2 to the
C FX processor (reverb).
FX D Send1 Send level of the Input 1 to the D FX
processor (modulating effect).
FX D Send2 Send level of the Input 2 to the D FX
processor (modulating effect).
FX D Send1/2 Send level of the Inputs 1 and 2 to the
D FX processor (modulating effect).
AssignPdl:In1/2Vol
AssignSld:CSend1/2
AssignSw1:FXMute
AssignSw2:Input 1 Mute
Gbl:IntFX Ctl
Parameter Meaning
Input 1 Mute Mute of the Input 1.
Input 2 Mute Mute of the Input 2.
Input 1/2 Mute Mute of both Inputs.
FX Mute Mute of the Internal FX processors on
the Audio Inputs.
Mode:Vocal
AssignPdl:HarmonyVol
Assign:Sld:FXSend
AssignSw1:Vcl/GtMute |
Gbl:Vocal/Guitar
Mode:Guitar |
AssignPdl:Hall Level
Assign:Sld:Hall Time
AssignSw1:Effect Mute |
Gbl:Vocal/Guitar
