Korg PA 80 User Manual

TOC-5
Assignable parameters . . . . . . . . . . . . . . . . . . . . 21-1
List of functions assignable to the Footswitch or
EC5 pedals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-1
List of functions assignable to the Pedal or
Assignable Slider . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-2
List of sounds assignable to the Pads . . . . . . . . . . . . . . . . 21-2
List of functions assignable to the Pads . . . . . . . . . . . . . . 21-3
Scales . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-3
MIDI Controllers . . . . . . . . . . . . . . . . . . . . . . . . . 22-1
MIDI Implementation Chart . . . . . . . . . . . . . . . . . . . . . . 22-2
Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-1
Recognized chords . . . . . . . . . . . . . . . . . . . . . . . 24-1
Vocal/Guitar Processor Board (VHG1) . . . . . . . . 25-1
Assembling the board with the HD drive already
installed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25-1
Assembling the board without a HD drive installed . . . .25-4
Video Interface (VIF1) . . . . . . . . . . . . . . . . . . . . . 26-1
Installing the board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26-1
Connections and setup . . . . . . . . . . . . . . . . . . . . . . . . . . . .26-3
Hard Disk Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-1
Error messages & Troubleshooting . . . . . . . . . . 28-1
Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28-1
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28-4
Technical specifications . . . . . . . . . . . . . . . . . . . 29-1
Alphabetical Index . . . . . . . . . . . . . . . . . . . . . . . 30-1

Korg PA 80 Specifications

General

Type	Arranger Workstation
Polyphony	62 voices
Sound Engine	HI (Hyper Integrated) synthesis system
ROM	32 MB PCM ROM
Keyboard	61 keys
Effects	4 Stereo Master Effects
Styles	304 styles
Style Tracks	8 Style Tracks
Sequencer	16-track
Display	Backlit LCD
Connectivity	MIDI (In, Out, Thru)
Floppy Disk	3.5 inch
Outputs	L/Mono, R
Inputs	Mic/Line input with gain control
