STEP 1
1
STEP 1
1. Main features of the TRINITY series
ACCESS
All models of the
TRINITY series
feature the
ACCESS
(Advanced Control Combined Synthesis
System), a PCM tone generation system that allows sound to be created completely in the digital
domain.
The tone generator has 24 Mbytes of PCM ROM, containing 375 multisamples and 258 drum sam-
ples recorded at a sampling frequency of 48 kHz. The multi-mode filter section provides four
types of filters (High Pass, Low Pass, Band Pass, and Band Reject) with resonance, for creative
flexibility.
The effect section provides 100 Insert Effects including effects such as equalizer, limiter, and
exciter which modify the tone or dynamics, effects such as amp simulation and rotary speaker
which bring out the tonal characteristics typical of certain instruments, and colorful effects such as
ring modulator, vocoder, and pitch shifter.
The effect section also provides a total of 14 Master Effects that can be selected for a modulation-
type master effect and for a reverb-type master effect, with adjustable sends and returns. All pro-
cessing is done in the digital domain for the highest sound quality.
MOSS
The
TRINITY V3
,
TRINITY V3 pro
, and
TRINITY V3 proX
also feature the
MOSS
(Multi Oscil-
lator Synthesis System).
The oscillators including Analog Simulation, VPM (Variable Phase Modulation) and Physical
Modeling allow especially expressive and powerful solo parts and synth bass parts. 64 sounds
using the MOSS tone generator are included in program bank M. (On the
TRINITY
, this capability
can be added by installing the MOSS-TRI option.)
Touch View
The
TRINITY series
is a revolutionary leap in operability and ease of use, thanks to its
Touch-
View Graphical User Interface
, which allows operation by touching directly on a large 320 x 240
dot LCD screen. More information can be displayed in the large LCD, so that parameter settings
can be viewed at a glance for much easier editing.
Expansion potential
The
TRINITY series
offers a wide variety of options, from the
MOSS-TRI option
to a
SCSI inter-
face
. Depending on the model, the number of preset programs and combinations and installed
functions will differ, but any model can be upgraded simply by installing options. When the
MOSS-TRI option
is installed in the
TRINITY
, the program banks will be expanded and you will
be able to access 64 sounds produced by the DSP-based MOSS tone generator.
Previous music workstations were not able to record audio data such as vocals or guitar. However
when the
HDR-TRI option
is installed, the
TRINITY
can record audio data as well. For example
you might record backing tracks on the internal MIDI sequencer, and record vocals on the HDR-
TRI option to complete a composition with vocals. This data can be backed up to DAT via the S/P
DIF option for the HDR-TRI option.
The PCM capacity can be expanded by installing the
Playback Sampler/Flash ROM option
. Sam-
ple data can be read into flash ROM, and used as a sound source. Program/Combination banks C
and D will be added, each providing an additional 128 program and combination areas. If the
MOSS-TRI option is installed, bank M will contain additional 64 program areas.
