11 FUEL TANK, SEAT, TRIM 69

G00817-12

– Lift the rear fairing.

–

Mount and tighten screws



Guideline

Screw, main silencer holder on fuel

tank

M8 25 Nm

(18.4 lbf ft)

G00816-12

–

Mount and tighten screws



Guideline

Screw, side cover M6 5 Nm (3.7 lbf ft)

Finishing work

– Install the air filter box. ( p. 59)

– Mount the side cover. ( p. 62)

– Disconnect the battery. ( p. 83)

– Mount the seat. ( p. 62)

– Set the clock. ( p. 99)
