Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA-3
1-2
Separation system Curvature separation + discharger needle (grounded) : except
100 V model
Curvature separation + discharger needle (DC voltage
impressed) : 100 V model only
Cleaning system Counter blade
Charge erasing system Exposure by cleaning lamp (LED)
Fusing system Sliding belt + foam press roller system
Heat source: halogen heater
Abnormal temperature preventing device: 2 thermocat
Operation Panel 2-line LCD LED
Memory 256 MB
Interface USB Interface Connector: 1 (Hi-Speed USB)
USB Port: 1 (Hi-Speed USB)
Network Network interface: 1
(10 BASE-T/100 BASE-TX/1000 BASE-T)
Wireless LAN Wireless LAN
support Only
- Wireless LAN
support Only
-
Operating
Environment
Temperature 10 to 32.5°C/50 to 90.5°F
Humidity 10 to 80%
Altitude 3,500 m/11,482 ft maximum
Brightness 1,500 lux maximum
Dimension (W × D × H) 14.77" × 15.48" × 10.71" 375 × 393 × 272 mm
Weight (without toner container) Approx. 30.9 lb/Approx. 14 kg
Space Required (W × D) (Using multi purpose tray) 14.77" × 28.47" 375 × 723 mm
Power Source AC100 V, 50/60 Hz, 9.5A
AC120 V, 60 Hz, 8.1A
AC220 to 240V, 50 Hz, 4.2A
*1 Up to upper limit height line in the cassette.
Item Description
40 ppm model 35 ppm model
P2040dw P2040dn P2235dw P2235dn

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
