Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-20
(2-8) Entire blank image (black)
(2-9) Part of the image is not copied
Step Check description Assumed cause Measures Reference
1 Reinstalling the drum unit The drum unit or main
charger unit is not attached
properly.
Reattach the main charger
unit to the drum unit and reat-
tach the drum unit to the main
unit so that it is securely
grounded.
2 Checking the main charger
contact
The main charger contact
is dirty or deformed.
Clean the main charger con-
tact and correct it for secure
grounding.
3 Checking the developer
bias contact
The developer bias contact
is dirty or deformed.
Clean the developer bias
contact or correct it to secure
ground.
4 Checking the connection The FFC is not properly
connected or faulty.
Reconnect the FFC. If the
FFC terminal is peel,
deformed or broken, replace
it.
• LSU (APC PWB) - Main/
engine PWB (YC505)
5 Checking the connection The connector is not prop-
erly connected or the wire
is faulty.
Clean the terminal of the fol-
lowing wire connectors and
reconnect the connectors. If
there is no continuity, replace
the wire.
• High voltage PWB - Main/
engine PWB (YC16)
6 Replacing the high voltage
PWB
The high voltage PWB is
faulty.
Replace the high voltage
PWB.
7 Replacing the LSU The LSU is dirty or faulty. Replace the LSU.
8 Replacing the main/engine
PWB
The main/engine PWB is
faulty.
Replace the main/engine
PWB.
Step Check description Assumed cause Measures Reference
1 Executing Drum refresh The drum surface is dirty. Execute Drum refresh.
2 Cleaning / replacing the
transfer roller
The transfer roller is dirty
or deformed.
Clean the transfer roller. If not
repaired, replace the transfer
roller.

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
