Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-30
(3) Paper jam detection condition
Main unit + document processor + paper feeder (option)
Figure 7-2
Error code and JAM location
Error
code
JAM
location
Error
code
JAM
location
Error
code
JAM
location
Error
code
JAM
location
J0000 - J0503 B J1413 J4203 C
J0101 - J0508 E J4002 A J4208 E
J0104 - J0509 A J4003 A J4209 C
C
B
B
B
B
A
D
C
E
1
5
2
3
4
6
7
8
[Paper jam location]
A. MP tray paper jam
B. Paper jam in the cassette 1 (to 3)
C. Paper jam inside the front cover
D. Paper jam inside the rear cover
E. Paper jam inside the duplex unit
[sensor(paper conveying)]
1. Paper sensor
2. MP paper sensor
3. Registration sensor
4. Eject sensor
5. PF paper sensor 1
6. PF feed sensor 1
7. PF paper sensor 2
8. PF feed sensor 2

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
