Kyocera Ecosys P2235dn - Developer Drive

2RV/2RW/2RX/2RY/3RA
3-19
(2-3) Developer drive
Figure 3-14
(2-4) Fuser unit drive
Figure 3-15
Main motor
Developer roller
Developer clutch
Developer screw A
Developer screw B
Lower eject roller
Main motor
Fuser belt
