Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-69
(2-2) Content of Self Diagnostic
C0100: Backup memory device error
An abnormal status is output from the flash memory.
C6030 Broken thermopile
C6050 Thermopile low temperature error
C6200 Fuser edge thermistor error
C6220 Fuser edge thermistor high temperature error
C6230 Broken fuser edge thermistor
C6250 Fuser edge thermistor low temperature error
C6400 Zero-cross signal error
C6600 Fuser rotation error
C6610 Fuser press-release sensor error
C6650 Thermopile EEPROM error
C7220 Broken in-machine thermistor
C7800 Outer thermistor broken
C7990 Waste toner full
Step Check description Assumed cause Measures Reference
1 Resetting the main power The EEPROM does not
operate properly.
Turn off the power switch and
unplug the power cord. After
5s passes, reconnect the
power cord and turn on the
power switch.
2 Reinstalling the EEPROM The EEPROM is not prop-
erly attached.
Reattach the EEPROM on
the main/engine PWB.
3 Replacing the EEPROM The EEPROM is faulty. Replace the EEPROM on the
main/engine PWB. After
replacement, C0180 appears
and execute U004.
4 Checking the main/engine
PWB
The connector is not con-
nected properly or the wire
or main/engine PWB is
faulty.
Reconnect the connector of
the main/engine PWB. If the
wire is pinched or scratched,
repair or replace it. If not
repaired, replace the main/
engine PWB.
Error code Contents

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
